■It is designed under overall engineering and ergonomic concept. All the components are processed with computer numerical controlled machine

■Specimen retraction function, protects specimen from blade injury

■Trimming/Cutting button makes it easy to switch from trim and section mode

■Equip with counter to calculate total pieces and thickness.

■Dual compressors, which are made in Germany, freeze the cryostat chamber, freezing shelf, knife holder and specimen clamp separate with pro-environment refrigerant R404

■Temperature can drop to working condition in 60 minutes after switching on.

■Adopt to UVC sterilize for 35 minutes every time.

■Peltier may be on or off manually.

■Heated, removable sliding window.

■Two defrost methods: definite time and manual

■The high-precision microtome is enclosed outside the cryostat chamber to protect it from thermal expansion and contraction and keep minimum service and maintenance.

■Self-explanatory symbols for all functions and displays, easy to learn and operate.

■LED screen can display data such as sample travel, thickness, function controlling, day, time, temperature, timed on/off and so on

■Stand by mode, after initializing, the temperature in cryostat chamber can be controlled between -4℃ an -9℃ by computer automatically; when stop initializing, the temperature in freeze chamber will arrive to working temperature within 10 minutes

■Control panel with locking function to avoid wrong operation.

■Handwheel locking

■Sensor self-diagnosis function.

■Wide freezing shelf may put 10 specimen cassettes

Technical Specifications

■freeze chamber temperature rage：-10℃～-30℃

■Cooling down time to -30℃：60 min

■Freeze shelf minimum temperature：-45℃

■Lowest temperature of Peltier unit on freeze shelf：-55℃

■Peltier working time: 15 minutes

■Maximum specimen size：35mm×35mm

■Specimen vertical stroke：60mm

■Specimen horizontal stroke：20mm

■Coarse feeding speed: 0.7mm/s; 0.35mm/s

■Section thickness range： 1μm～80μm adjustable;  1μm～20μm, in 1μm increment

20μm～40μm, in 2μm increments;  40μm～80μm, in 5μm increments

■Trimming thickness range：10μm～400μm adjustable; 10μm～50μm, in 5μm increments; 50μm～100μm, in 10μm increments; 100μm～400μm, in 50μm increments;

■Retraction range: 0μm～80μm adjustable; in 5μm increment

■Voltage and frequency：AC220V±10%   50Hz(Standard) Special requirement may customize by order.

■Power：850W

■Weight：130kg

■Dimensions(W×D×H)：660×640×1130mm
